Introduction
This vignette introduces survival analysis with RLT (Reinforcement Learning Trees). RLT survival forests estimate individual survival, hazard, and cumulative hazard functions via ensemble tree methods. Key features include:
- Three split rules: logrank (default), suplogrank, and coxgrad.
- Linear combination (LC) splits: combine multiple variables into a single split direction.
- Variance estimation: matched-sample U-statistic, infinitesimal jackknife (IJ), and jackknife.
-
Confidence bands:
get.surv.band()provides naive or smoothed simultaneous bands for survival curves. -
Tree inspection:
get.one.tree()inspects individual tree structures.
The examples below use small simulated datasets so that all code runs quickly.
Simulated data
We simulate data from a proportional hazards model with exponential event times. The first two predictors carry signal; the rest are noise. About 30% of observations are censored.
set.seed(42)
n <- 200
p <- 5
X <- matrix(rnorm(n * p), n, p)
colnames(X) <- paste0("V", 1:p)
beta <- c(0.8, 0.5, 0, 0, 0)
hazard <- exp(X %*% beta)
surv_time <- rexp(n, rate = hazard)
censor_time <- runif(n, 0, 3)
y <- pmin(surv_time, censor_time)
censor <- as.numeric(surv_time <= censor_time)
table(censor)
#> censor
#> 0 1
#> 76 124Basic usage
Fit a survival forest with model = "survival". The third
argument is the censoring indicator (1 = event observed,
0 = censored). By default
split.rule = "logrank".
library(RLT)
fit <- RLT(X, y, censor,
model = "survival",
ntrees = 100,
nmin = 5,
verbose = FALSE)
fit
#> --------------------------------------
#> RLT Survival Forest
#> --------------------------------------
#> (N, P) = (200, 5)
#> # of trees = 100
#> (mtry, nmin) = (2, 5)
#> split generate = Best
#> sampling = 100% w/ replace
#> importance = none
#> OOB error = 0.3283
#> --------------------------------------Predict on new data (or the training data) to obtain survival curves, hazards, and cumulative hazards:
pred <- predict(fit, X[1:5, ])
# Each component is an N x T matrix, where T is the number of unique failure times
str(pred$Survival) # Survival function S(t)
#> num [1:5, 1:124] 1 1 0.98 0.985 1 ...
str(pred$Hazard) # Hazard function h(t)
#> num [1:5, 1:124] 0 0 0.02 0.015 0 0.002 0 0 0 0 ...
str(pred$CHF) # Cumulative hazard H(t)
#> num [1:5, 1:124] 0 0 0.02 0.015 0 0.002 0 0.02 0.015 0 ...
# For survival forests, $Prediction is NULL
pred$Prediction
#> NULLPlot the predicted survival curve for the first subject:
plot(pred$timepoints, pred$Survival[1, ], type = "s",
xlab = "Time", ylab = "Survival Probability",
main = "Predicted Survival Curve (Subject 1)")
Split rules
RLT provides three splitting criteria for survival trees:
| Rule | Description | Best for |
|---|---|---|
logrank |
Standard log-rank test statistic (default) | General use, clear hazard differences |
suplogrank |
Supremum (maximum) of the standardized log-rank process over time | Non-proportional hazards, time-varying effects |
coxgrad |
Gradient of Cox partial likelihood | When a Cox-like direction is plausible; supports observation weights |
Fit the three rules on the same data and compare out-of-bag error estimates:
fit_lr <- RLT(X, y, censor, model = "survival", ntrees = 100,
split.rule = "logrank", verbose = FALSE)
fit_slr <- RLT(X, y, censor, model = "survival", ntrees = 100,
split.rule = "suplogrank", verbose = FALSE)
fit_cg <- RLT(X, y, censor, model = "survival", ntrees = 100,
split.rule = "coxgrad", verbose = FALSE)
c(logrank = fit_lr$Error, suplogrank = fit_slr$Error, coxgrad = fit_cg$Error)
#> logrank suplogrank coxgrad
#> 0.3341685 0.3252302 0.3718174In practice, logrank is a safe default.
suplogrank can be advantageous when hazard ratios change
over time. coxgrad is useful when you want to incorporate
observation weights (see below) or when the data follow a Cox-like
structure.
Observation weights
Observation weights are passed via obs.w. For survival
forests, weights are not used by logrank
or suplogrank (due to the difficulty of weighted variance
estimation for the test statistic), but they are used
by coxgrad.
w <- runif(n)
fit_w <- RLT(X, y, censor, model = "survival", ntrees = 100,
split.rule = "coxgrad", obs.w = w, verbose = FALSE)
fit_w
#> --------------------------------------
#> RLT Survival Forest
#> --------------------------------------
#> (N, P) = (200, 5)
#> # of trees = 100
#> (mtry, nmin) = (2, 5)
#> split generate = Best
#> sampling = 100% w/ replace
#> obs weights = Yes
#> importance = none
#> OOB error = 0.3717
#> --------------------------------------Linear combination splits
When linear.comb > 1, each split uses a linear
combination of linear.comb variables instead of a single
variable. For survival forests, the available methods are:
-
"coxph"(default): coefficients from a local Cox model fit. -
"naive": simple correlation-based direction.
Specify these through param.control:
fit_lc <- RLT(X, y, censor,
model = "survival",
ntrees = 100,
split.rule = "logrank",
param.control = list(
linear.comb = 3,
linear.comb.method = "coxph"
),
verbose = FALSE)
fit_lc
#> ----------------------------------------
#> RLT Survival Forest (Linear Combination)
#> ----------------------------------------
#> (N, P) = (200, 5)
#> # of trees = 100
#> (mtry, nmin) = (2, 5)
#> split generate = Best
#> linear combination split = 3
#> sampling = 100% w/ replace
#> importance = none
#> OOB error = 0.3148
#> ----------------------------------------Predictions from LC forests have the same structure as standard forests:
Variable importance
Set importance = TRUE to compute variable importance.
The importance measure for survival forests is based on the decrease in
the splitting criterion (logrank, suplogrank, or coxgrad).
fit_imp <- RLT(X, y, censor,
model = "survival",
ntrees = 100,
importance = TRUE,
verbose = FALSE)
importance(fit_imp)
#> Variable VI
#> --------------------------
#> V1 0.0763
#> V2 0.0283
#> V3 0.0038
#> V4 -0.0008
#> V5 -0.0007When variance estimation is enabled (see next section),
importance() also reports standard errors, Z-scores, and
significance codes.
Variance estimation and confidence bands
RLT supports three variance estimation strategies for survival predictions:
-
"matched": matched-sample U-statistic decomposition. Requires an even number of trees and subsampling without replacement at 50% (automatically adjusted). -
"IJ": infinitesimal jackknife. -
"jack": jackknife variance.
Enable variance estimation during fitting via var.mode,
then request covariance matrices at prediction time with
var.est = TRUE.
The following example uses eval = FALSE because reliable
variance estimation typically requires many trees (e.g., 1,000+).
fit_var <- RLT(X, y, censor,
model = "survival",
ntrees = 1000,
var.mode = "matched",
verbose = FALSE)
# Predict with variance estimation
pred_var <- predict(fit_var, X[1:3, ], var.est = TRUE)
# pred_var$Cov is a T x T x N array: covariance of the cumulative hazard over time
str(pred_var$Cov)
# Marginal variances and critical values for bands
str(pred_var$MarginalVar)
str(pred_var$CVproj)Confidence bands with get.surv.band()
Given a prediction object with variance information,
get.surv.band() computes simultaneous confidence bands for
the survival function. Two approaches are available:
-
"naive": uses the full covariance matrix with a Monte Carlo critical value. -
"smoothed": GAM-smoothed low-rank covariance plus eigenvalue-ratio weighted residual correction.
# Naive band for the first test subject
band_naive <- get.surv.band(pred_var, i = 1, alpha = 0.05,
approach = "naive", nsim = 5000)
# Smoothed band
band_smooth <- get.surv.band(pred_var, i = 1, alpha = 0.05,
approach = "smoothed",
nsim = 5000, k_rank = 10)
# Plot survival curve with naive band
t <- band_naive$timepoints
plot(t, pred_var$Survival[1, ], type = "s", ylim = c(0, 1),
xlab = "Time", ylab = "Survival",
main = "Survival Curve with 95% Confidence Band")
lines(t, band_naive$Subject1$lower, type = "s", col = "blue", lty = 2)
lines(t, band_naive$Subject1$upper, type = "s", col = "blue", lty = 2)
legend("topright", legend = c("Estimate", "95% Band"),
col = c("black", "blue"), lty = c(1, 2))You can also request all subjects at once with i = 0
(the default).
Reducing the time grid for bands
For large datasets, the full set of failure times can make covariance
matrices unwieldy. Use band.grid.size in
predict() to evaluate variance on a reduced quantile-based
grid:
Inspecting individual trees
Use get.one.tree() to inspect the structure of any tree
in the fitted forest. The preview below shows the first few printed
lines so the tutorial stays compact.
# Standard (single-variable) survival tree
tree_output <- capture.output(get.one.tree(fit, tree = 1))
cat(head(tree_output, 14), sep = "\n")
#> Tree #1 [Survival]
#>
#> Node Depth Split Value n
#> --------------------------------------------------------------
#> 1 0 V3 -1.9954 189
#> 2 1 V2 0.8901 4
#> 3 1 V1 1.7690 3
#> 4 2 V4 -0.5430 3
#> 5 2 * - 4
#> 6 3 * - 4
#> 7 3 * - 3
#> 8 2 V2 1.0553 30
#> 9 2 * - 3
#> 10 3 V1 -0.1216 84
if (length(tree_output) > 14) {
cat("\n... output truncated ...\n")
}
#>
#> ... output truncated ...For LC forests, get.one.tree() also shows the linear
combination coefficients at each internal node:
tree_output <- capture.output(get.one.tree(fit_lc, tree = 1))
cat(head(tree_output, 14), sep = "\n")
#> Tree #1 [Survival, Linear Combination]
#>
#> Node Depth Split Value n
#> --------------------------------------------------------------
#> 1 0 0.453·V5 + 0.891·V3 2.0860 200
#> 2 1 0.395·V5 - 0.919·V4 -1.9186 193
#> 3 1 * - 7
#> 4 2 * - 2
#> 5 2 0.999·V1 + 0.036·V3 0.2900 191
#> 6 3 0.996·V1 - 0.088·V4 -0.0492 108
#> 7 3 0.975·V2 + 0.223·V1 1.0275 83
#> 8 4 0.989·V2 + 0.151·V4 -0.4532 80
#> 9 4 0.914·V5 + 0.405·V3 0.3363 28
#> 10 5 0.933·V5 + 0.360·V3 0.4243 16
if (length(tree_output) > 14) {
cat("\n... output truncated ...\n")
}
#>
#> ... output truncated ...Summary
- Fit a survival forest with
RLT(x, y, censor, model = "survival", ...). - Predict with
predict(fit, testx)to obtain$Survival,$Hazard, and$CHF. - Choose
split.ruleamong"logrank","suplogrank", and"coxgrad". - Use
obs.wwithsplit.rule = "coxgrad"for weighted splits. - Enable LC splits via
param.control = list(linear.comb = k, linear.comb.method = "coxph"). - Request variable importance with
importance = TRUEand inspect viaimportance(fit). - Estimate prediction variance with
var.mode = "matched"/"IJ"/"jack", then callpredict(..., var.est = TRUE). - Build confidence bands with
get.surv.band(pred, approach = "naive" or "smoothed"). - Inspect trees with
get.one.tree(fit, tree = k).
