## Overview

This document summarizes the CartPole (inverted pendulum) environment and the simulation design used to generate offline data for reinforcement learning methods such as Fitted Q-Iteration. In Python, there are some standard libraries such as the [`gymnasium`](https://gymnasium.farama.org/) library that implement this environment. Here I try to reproduce the environment dynamics in `R` and physical models based on publicly available information. Since many of the tuning parameters are different, the dynamic will not behave the same as the Gym library.

## Physical Model and Parameters

<div style="text-align: center;">
  <img src="cartpole.png" width="60%" />
</div>

The environment is a continuous-state, discrete- or continuous-action Markov decision process with deterministic transitions. The goal is to keep the pole upright and the cart within the track for as long as possible. We consider a cart of mass \(m_c\) moving on a frictionless track, with a pole of mass \(m_p\) and total length \(2\ell\), hinged at the cart. The physical parameters used throughout are:

\[
\begin{aligned}
g &= 9.8 \ \text{m/s}^2 \\
m_c &= 1.0 \ \text{kg} \\
m_p &= 0.1 \ \text{kg} \\
m_{\text{tot}} &= m_c + m_p = 1.1 \ \text{kg} \\
\ell &= 0.5 \ \text{m} \\
m_p \ell &= 0.05\ \text{kg·m}
\end{aligned}
\]

Parameter that controls our data generator

\[
\begin{aligned}
\text{max force:} \qquad F_{\max} &= 5 \ \text{N}\\
\text{max bound:} \qquad x_{\max} &= 0.2 \ \text{m} \\
\text{max angle:} \qquad \theta_{\max} &= 15^\circ \approx 0.2095\ \text{rad} \\
\text{step size:} \qquad \quad \,\, \tau &= 0.01\ \text{s} \\
\end{aligned}
\]

These parameters are chosen to match widely used implementations of the CartPole environment.

## State space

The state at time \(t\) is

\[
S_t = (x_t, \dot x_t, \theta_t, \dot\theta_t) \in \mathbb{R}^4,
\]

where

- \(x_t\): cart horizontal position (meters),
- \(\dot x_t\): cart velocity (m/s),
- \(\theta_t\): pole angle relative to upright (radians),
- \(\dot\theta_t\): pole angular velocity (rad/s).

Episodes start from small random perturbations around the upright equilibrium:

\[
(x_0, \dot x_0, \theta_0, \dot\theta_0)
\sim \text{Uniform}([-0.05, 0.05]^4).
\]

## Action space and applied force

The environment accepts either discrete or continuous actions, all interpreted on the interval \([-1, 1]\).

- Discrete actions:
  \[
  A_t \in \{-1, +1\}
  \]
  representing a full-magnitude push to the left or right.

- Continuous actions:
  \[
  A_t \in [-1, +1]
  \]

In all cases, the horizontal force applied to the cart is

\[
F_t = A_t \, F_{\max},
\qquad |F_t| \le F_{\max}.
\]

Thus discrete actions are a special case of the continuous control range.

## Reward function

Two reward structures are considered.

1. Survival-type reward:

   \[
   R_t =
   \begin{cases}
   1, & \text{if } |x_{t+1}| \le 0.1 \text{ and } |\theta_{t+1}| \le 0.1, \\
   0, & \text{otherwise}.
   \end{cases}
   \]

   This encourages policies that keep the system within safe bounds for as many steps as possible.

2. Quadratic shaping reward:

   \[
   R_t = - \left( 0.01 \, x_{t+1}^2
                 + 100 \, \theta_{t+1}^2
                 + 0.01 \, \dot x_{t+1}^2
                 + 0.1 \, \dot\theta_{t+1}^2 \right).
   \]

   This penalizes deviation from the upright equilibrium in both position and velocity.

## Termination conditions

An episode terminates at the first time step \(t\) for which

\[
|x_t| > x_{\max}
\quad\text{or}\quad
|\theta_t| > \theta_{\max}.
\]

In practice, an additional maximum horizon \(T_{\max}\) (for example 200 or 500) may be imposed, in which case an episode also terminates if \(t \ge T_{\max}\).

## Continuous Transitional Dynamics

Given the current state

\[
(x, \dot x, \theta, \dot\theta)
\]

and the applied force \(F\), define

\[
\text{temp}
=
\frac{F + (m_p \ell)\,\dot\theta^{2}\,\sin(\theta)}{m_{\text{tot}}}.
\]

The angular acceleration of the pole and the horizontal acceleration of the cart are

\[
\theta_{\text{acc}}
=
\frac{
g\,\sin(\theta) - \cos(\theta)\,\text{temp}
}{
\ell\left(
\frac{4}{3} - \frac{m_p \cos^{2}(\theta)}{m_{\text{tot}}}
\right)
},
\]

\[
x_{\text{acc}}
=
\text{temp}
-
\frac{m_p \ell\, \theta_{\text{acc}}\, \cos(\theta)}{m_{\text{tot}}}.
\]

These nonlinear equations follow from Newtonian mechanics applied to the coupled cart-pole system. We discretize the dynamics using a fixed time step \(\tau = 0.01\) and semi-implicit (symplectic) Euler integration:

\[
\begin{aligned}
\dot x_{t+1} &= \dot x_t + \tau\, x_{\text{acc},t}, \\
x_{t+1}      &= x_t      + \tau\, \dot x_{t+1}, \\
\dot\theta_{t+1} &= \dot\theta_t + \tau\, \theta_{\text{acc},t}, \\
\theta_{t+1}     &= \theta_t     + \tau\, \dot\theta_{t+1}.
\end{aligned}
\]

The mapping \((S_t, A_t) \mapsto S_{t+1}\) is deterministic.

## Simulation environment and step function

The following R code implements the CartPole dynamics to roll out the next step of the episode:

```{r}
  # CartPole environment with actions in [-1, 1]
  cartpole_step <- function(state, action,
                            reward.method = "discrete") {

    # Unpack state
    x         <- state[1]
    x_dot     <- state[2]
    theta     <- state[3]
    theta_dot <- state[4]

    # Parameters
    g  <- 9.8
    m_c <- 1.0
    m_p <- 0.1
    l   <- 0.5
    F_max <- 5
    tau <- 0.01
    x_th <- 0.2
    theta_th <- 12 * (pi / 180)

    total_mass <- m_c + m_p

    # Action in [-1, 1]; discrete {-1, +1} is a special case
    f <- action * F_max

    # Compute accelerations
    costheta <- cos(theta)
    sintheta <- sin(theta)

    temp <- (f + m_p * l * theta_dot^2 * sintheta) / total_mass

    theta_acc <- (g * sintheta - costheta * temp) /
                 (l * (4/3 - (m_p * costheta^2) / total_mass))

    x_acc <- temp - (m_p * l * theta_acc * costheta) / total_mass

    # Update state using semi-implicit Euler
    x_dot_new     <- x_dot + tau * x_acc
    x_new         <- x + tau * x_dot_new
    theta_dot_new <- theta_dot + tau * theta_acc
    theta_new     <- theta + tau * theta_dot_new

    new_state <- c(x_new, x_dot_new, theta_new, theta_dot_new)

    # Compute termination
    done <- (abs(x_new) > x_th) ||
            (abs(theta_new) > theta_th)

    # Compute reward
    if (reward.method == "discrete") {
      reward <- ifelse(abs(theta_new) > 0.1 | abs(x_new) > 0.1, 0, 1)
    } else if (reward.method == "continuous") {
      reward <- - ( 0.01 * x_new^2 + # position loss
                    100 * theta_new^2 + # angle loss
                    0.01 * x_dot_new^2 + # position stability
                    0.1 * theta_dot_new^2) # angle stability
    } else {
      stop("Unknown reward.method")
    }

    return(list(state = new_state, reward = reward, done = done))
  }

  # Function to initialize the cartpole state
  cartpole_initial <- function() {
    state <- runif(4, min = -0.05, max = 0.05)
    return(state)
  }
```

We can then generate a dataset of such transitions for use in offline reinforcement learning experiments. For this example, we will use a random policy that samples actions from the discrete set \(\{-1, +1\}\).

```{r}
  generate_cartpole <- function(n_episode = 1,
                                T_max = 200,
                                reward.method = "discrete",
                                policy = function(state) {
                                  sample(c(-1, 1), 1)
                                }) {

    all_rows <- list()    # store rows before binding
    row_id <- 1

    for (ep in 1:n_episode) {

      state <- cartpole_initial()

      for (t in 1:T_max) {

        # Generate action
        A_t <- policy(state)

        # check action range
        if (abs(A_t) > 1) {
          stop("Action out of range [-1, 1]")
        }

        # Step the environment
        out <- cartpole_step(state, A_t, reward.method = reward.method)

        S_next <- out$state
        R_t    <- out$reward
        done   <- out$done

        # Record (S_t, A_t, R_t)
        all_rows[[row_id]] <- data.frame(
          episode = ep,
          time    = t,
          x       = state[1],
          x_dot   = state[2],
          theta   = state[3],
          theta_dot = state[4],
          action  = A_t,
          reward  = R_t
        )
        row_id <- row_id + 1

        # Move to next state
        state <- S_next

        if (done) break
      }
    }

    # Combine into a dataframe
    batch_data <- do.call(rbind, all_rows)
    rownames(batch_data) <- NULL
    return(batch_data)
  }

  set.seed(546)
  cartpole_data = generate_cartpole()

  head(cartpole_data)
```

To visualize the generated data, we can plot the cart position and pole angle over time for a few episodes.

```{r, out.width='100%'}
  # Generate 10 episodes of discrete {-1, +1} data
  set.seed(432)
  cartpole_data <- generate_cartpole(n_episode = 10)

  # plot the trajectories of the cart position and rewards
  library(ggplot2)
  library(patchwork)

  plot_cartpole <- function(data) {

    p1 <- ggplot(data, aes(x = time, y = x, color = factor(episode))) +
      geom_line() +
      labs(title = "Cart Position (x)", x = "Time", y = "x") +
      theme_minimal() +
      scale_y_continuous(limits = c(-0.2, 0.2)) +
      theme(legend.position = "none")

    p2 <- ggplot(data, aes(x = time, y = x_dot, color = factor(episode))) +
      geom_line() +
      labs(title = "Cart Velocity (x_dot)", x = "Time", y = "x_dot") +
      theme_minimal() +
      theme(legend.position = "none")

    p3 <- ggplot(data, aes(x = time, y = theta, color = factor(episode))) +
      geom_line() +
      labs(title = "Pole Angle (theta)", x = "Time", y = "theta") +
      theme_minimal() +
      scale_y_continuous(limits = c(-12 * (pi / 180), 12 * (pi / 180))) +
      theme(legend.position = "none")

    p4 <- ggplot(data, aes(x = time, y = theta_dot, color = factor(episode))) +
      geom_line() +
      labs(title = "Pole Angular Velocity (theta_dot)", x = "Time", y = "theta_dot") +
      theme_minimal() +
      theme(legend.position = "none")

    p5 <- ggplot(data, aes(x = time, y = reward, color = factor(episode))) +
      geom_line() +
      labs(title = "Reward", x = "Time", y = "reward") +
      theme_minimal() +
      theme(legend.position = "none")

    # 2x2 layout
    (p1 | p2) /
    (p3 | p4) /
    p5
  }

  plot_cartpole(cartpole_data)
```
